Built-in portal applications

caddy-security v1.6.2, using go-authcrunch v1.5.0, includes three browser applications inside the executable. Open the authentication portal, sign in, and choose an application. You do not need Node.js, a separate frontend server, or a static-file deployment to use the bundled apps.

Application	With a portal at `/auth`	Purpose	Access
User Profile	`/auth/profile/`	Account information, credentials, authenticators, connected accounts and login rules	`authp/user` or `authp/admin`; profile operations keep their own API/session requirements
Security Manager	`/auth/operator/`	Identity stores, users, roles, authentication rules, signing keys and service information	Enabled Admin API and `authp/admin`
File Vault	`/auth/documents/`	Locally encrypted files, downloads, recipient sharing and recovery keys	Enabled and initialized Documents API and `authp/user` or `authp/admin`; file operations require a current local browser login

The portal computes these links for the signed-in account. A user sees no Security Manager link, and disabled features have no application link. Direct requests still enforce the application's role and feature checks. The Profile shell is available independently of its API; opening it does not establish permission to change a local account.

The released v1.6.2 executable adds the three links automatically. Alice has both portal roles in the example below.

Run all three locally

Install the caddy-security v1.6.2 executable or the AuthCrunch v1.6.2 distribution. The latter includes the optional backend companions. These apps and the local JSON/Documents features used here do not require an extra companion. Verify the checksum from the repository that supplied your archive; the two repositories use the same archive filenames.

Create an empty working directory, save the configuration below there as Caddyfile, and prepare its private data directory:

mkdir -p data
chmod 700 data
export AUTHCRUNCH_APPS_DATA_DIR="$PWD/data"
authcrunch version
authcrunch security version
authcrunch adapt --config Caddyfile --adapter caddyfile > /dev/null
authcrunch run --config Caddyfile --adapter caddyfile

security version should report go-authcrunch v1.5.0 for the selected release. The configuration uses HTTPS on localhost:8443 and a loopback certificate approval endpoint on port 5555. Both ports must be free. Its local CA is not installed in your system trust store; accept the local certificate exception only for this exercise or use a browser that already trusts your local CA.

Local demonstration configuration

The passwords and signing key below are public demo values. Run this example only on your own workstation with disposable accounts and files. Production needs your hostname, trusted HTTPS, private signing material, appropriate roles, and protected durable storage. The example enables account administration.

Caddyfile
# Embedded portal apps: caddy-security v1.6.2 / go-authcrunch v1.5.0.
# Local learning only: public demo credentials and signing key; no environment variables.
{
	admin off
	persist_config off
	auto_https disable_redirects
	skip_install_trust
	on_demand_tls {
		ask http://localhost:5555/
	}
	storage file_system ./data/caddy

	security {
		local identity store localdb {
			realm local
			path ./data/users.json
			user alice {
				name Alice Example
				email alice@example.test
				password "LocalDemoPassword123!"
				roles authp/admin authp/user app/member
			}
			user bob {
				name Bob Example
				email bob@example.test
				password "LocalDemoPassword123!"
				roles authp/user
			}
		}

		authentication portal myportal {
			enable identity store localdb
			enable admin api
			enable documents api
			documents api database {env.AUTHCRUNCH_APPS_DATA_DIR}/documents.db
			documents api public origin https://localhost:8443
			documents api base path /auth
			documents api realms local
			crypto default token lifetime 300
			crypto key sign-verify "LocalDemoSigningKey-ChangeBeforeDeployment-0123456789"
			cookie guess domain enabled
			cookie prefix AUTHTEST
			trust login redirect uri domain exact localhost:8443 path prefix /
			ui {
				links {
					"Example app" / icon "las la-external-link-alt"
				}
			}
		}

		authorization policy apppolicy {
			set auth url https://localhost:8443/auth/login
			crypto key verify "LocalDemoSigningKey-ChangeBeforeDeployment-0123456789"
			allow roles authp/admin authp/user
			set session_id cookie name AUTHTEST_SESSION_ID
			set access_token cookie name AUTHTEST_ACCESS_TOKEN
		}
	}
}

http://localhost:5555 {
	bind 127.0.0.1
	@allowed_localhost query domain=localhost
	respond @allowed_localhost 200
	respond 400
}

https://localhost:8443 {
	bind 127.0.0.1
	tls internal {
		on_demand
	}

	route /healthz {
		respond "AuthCrunch demo is running." 200
	}

	@portal path /auth /auth/*
	route @portal {
		redir /auth /auth/ 308
		authenticate with myportal at /auth
	}

	route /* {
		authorize with apppolicy
		respond "You reached the protected app." 200
	}
}

Account	Password	Expected applications
`alice`	`LocalDemoPassword123!`	User Profile, Security Manager, File Vault
`bob`	`LocalDemoPassword123!`	User Profile, File Vault

Alice is the administrator. Use Bob in a separate browser profile or private window when testing sharing or denied administrative access. The local store can also create its bootstrap administrator; use the named accounts above for this walkthrough.

The account database is data/users.json; encrypted documents are in data/documents.db; local certificate state is under data/caddy. Keep these private and outside served directories. The Documents path must be absolute, which is why the command supplies AUTHCRUNCH_APPS_DATA_DIR. Retain the same account store and portal binding when restarting if you want to retain file access. Stop the foreground process with Ctrl+C when finished.

Follow the application walkthroughs

User Profile: inspect your account, manage credentials, enroll an authenticator, and review effective login rules.
Security Manager: inspect a realm, create a disposable user, edit roles/rules, and understand protected signing-key export.
File Vault: save a recovery key, enroll and unlock, upload and download, share with Bob, revoke access, and review reset consequences.

The sidebar switches app pages; the avatar menu contains Preferences, Diagnostics, Portal, and Sign out. On phones the sidebar becomes a drawer. Preferences change this browser's language, timezone and appearance; they do not change server authentication policy. Diagnostics helps distinguish the UI version from the server/library version.

Deploy at a different portal mount

Keep the complete request path when delegating to authenticate. The portal serves the application HTML, assets, fonts, translations, and deep links itself; do not strip /auth or add a Vite proxy for these bundled applications.

Portal mount	Profile	Security Manager	File Vault
`/`	`/profile/`	`/operator/`	`/documents/`
`/auth`	`/auth/profile/`	`/auth/operator/`	`/auth/documents/`
`/company/auth`	`/company/auth/profile/`	`/company/auth/operator/`	`/company/auth/documents/`

For a nested mount, change the route matcher, bare-mount redirect, authenticate ... at argument, authorization login URL, and Documents base path together. For a root mount, use / as the explicit mount and Documents base path. The Documents public origin remains only the HTTPS scheme, hostname and optional port. Its database binds the portal name, public origin and base path: moving an existing encrypted database is a separate migration problem, not a link edit.

The portal injects each app's canonical HTML base. Reloading a deep link uses that same base for lazy-loaded code and translations. Missing files under assets/ or i18n/ return 404 instead of application HTML. Portal CSS/template overrides do not rebuild or restyle the embedded React apps.

Check access and diagnose failures

Check or symptom	Expected result or next step
Alice opens all three links	App content loads; File Vault initially asks for vault enrollment
Bob opens `/auth/operator/` directly	Access is denied even though he is signed in
Documents or Admin API disabled	The corresponding app is unavailable and its portal link is omitted
Profile opens but account actions fail	Check local-account authority, Profile API availability, and fresh browser login; shell access alone is insufficient
Documents reports a permission error	Check the local login, admitted realm, exact HTTPS origin and portal mount; an administrator cannot bypass document ownership
Deep link loads HTML as JavaScript or loses assets	Verify full path delegation and the selected release; remove unrelated static/proxy catchalls
Session expires	Follow the app back to portal authentication; unlock File Vault again after fresh login

The example was adapted and run with the checksum-verified caddy-security v1.6.2 macOS arm64 archive. Browser checks covered both roles, the three app entries, Documents bootstrap, deep-link pages, and missing-asset rejection. See feature versions for earlier baselines.

Agentic Prompts

Use a prompt to explore this workflow against your deployed release.

Explain who sees each app

Primary authorities, before website documentation:
https://github.com/greenpau/caddy-security/blob/main/AGENTS.md
https://github.com/greenpau/caddy-security/tree/main/.codex/skills
https://github.com/greenpau/go-authcrunch/blob/main/AGENTS.md
https://github.com/greenpau/go-authcrunch/tree/main/.codex/skills
Read each root AGENTS.md first, then any scoped AGENTS.md applying to inspected
paths, then the relevant SKILL.md files and their implementation/test references.
Distinguish main, caddy-security v1.6.2 / go-authcrunch v1.5.0, the UI asset
version, and my deployed release. Resolve differences with code/tests. Keep
unverified behavior uncertain. Ask for pasted sources if they are inaccessible.
Use synthetic or redacted inputs; never request tokens or recovery secrets.
Relevant skills to locate: configuration-authentication-ui; configuration-http-integrations; application-implementation.
Secondary context: https://docs.authcrunch.com/docs/apps/portal-apps

Trace portal menu construction, app enablement and server role checks for a user and an administrator. Explain why a hidden link is not the access-control boundary and why Profile shell access differs from API authority.

Deploy under a nested mount

Primary authorities, before website documentation:
https://github.com/greenpau/caddy-security/blob/main/AGENTS.md
https://github.com/greenpau/caddy-security/tree/main/.codex/skills
https://github.com/greenpau/go-authcrunch/blob/main/AGENTS.md
https://github.com/greenpau/go-authcrunch/tree/main/.codex/skills
Read each root AGENTS.md first, then any scoped AGENTS.md applying to inspected
paths, then the relevant SKILL.md files and their implementation/test references.
Distinguish main, caddy-security v1.6.2 / go-authcrunch v1.5.0, the UI asset
version, and my deployed release. Resolve differences with code/tests. Keep
unverified behavior uncertain. Ask for pasted sources if they are inaccessible.
Use synthetic or redacted inputs; never request tokens or recovery secrets.
Relevant skills to locate: configuration-authentication-ui; configuration-http-integrations; application-implementation.
Secondary context: https://docs.authcrunch.com/docs/apps/portal-apps

Walk through moving a fresh synthetic portal from /auth to /company/auth. Identify every route, redirect, login URL, Documents binding and asset base that must agree. Separate a new deployment from migration of an existing Documents database.

Diagnose a broken deep link

Primary authorities, before website documentation:
https://github.com/greenpau/caddy-security/blob/main/AGENTS.md
https://github.com/greenpau/caddy-security/tree/main/.codex/skills
https://github.com/greenpau/go-authcrunch/blob/main/AGENTS.md
https://github.com/greenpau/go-authcrunch/tree/main/.codex/skills
Read each root AGENTS.md first, then any scoped AGENTS.md applying to inspected
paths, then the relevant SKILL.md files and their implementation/test references.
Distinguish main, caddy-security v1.6.2 / go-authcrunch v1.5.0, the UI asset
version, and my deployed release. Resolve differences with code/tests. Keep
unverified behavior uncertain. Ask for pasted sources if they are inaccessible.
Use synthetic or redacted inputs; never request tokens or recovery secrets.
Relevant skills to locate: configuration-authentication-ui; configuration-http-integrations; application-implementation.
Secondary context: https://docs.authcrunch.com/docs/apps/portal-apps

Analyze a deep-link reload that returns HTML as JavaScript. Compare canonical base injection, missing-asset 404 handling, path preservation and an unrelated proxy catchall. Propose focused observations before a configuration change.

Compare embedded and development hosting

Primary authorities, before website documentation:
https://github.com/greenpau/caddy-security/blob/main/AGENTS.md
https://github.com/greenpau/caddy-security/tree/main/.codex/skills
https://github.com/greenpau/go-authcrunch/blob/main/AGENTS.md
https://github.com/greenpau/go-authcrunch/tree/main/.codex/skills
Read each root AGENTS.md first, then any scoped AGENTS.md applying to inspected
paths, then the relevant SKILL.md files and their implementation/test references.
Distinguish main, caddy-security v1.6.2 / go-authcrunch v1.5.0, the UI asset
version, and my deployed release. Resolve differences with code/tests. Keep
unverified behavior uncertain. Ask for pasted sources if they are inaccessible.
Use synthetic or redacted inputs; never request tokens or recovery secrets.
Relevant skills to locate: configuration-authentication-ui; configuration-http-integrations; application-implementation.
Secondary context: https://docs.authcrunch.com/docs/apps/portal-apps

Explain which process serves the production embedded apps and which processes serve the separately developed React source. Compare integration, library and UI versions without prescribing a Vite deployment for a bundled app.

Design the access walkthrough

Primary authorities, before website documentation:
https://github.com/greenpau/caddy-security/blob/main/AGENTS.md
https://github.com/greenpau/caddy-security/tree/main/.codex/skills
https://github.com/greenpau/go-authcrunch/blob/main/AGENTS.md
https://github.com/greenpau/go-authcrunch/tree/main/.codex/skills
Read each root AGENTS.md first, then any scoped AGENTS.md applying to inspected
paths, then the relevant SKILL.md files and their implementation/test references.
Distinguish main, caddy-security v1.6.2 / go-authcrunch v1.5.0, the UI asset
version, and my deployed release. Resolve differences with code/tests. Keep
unverified behavior uncertain. Ask for pasted sources if they are inaccessible.
Use synthetic or redacted inputs; never request tokens or recovery secrets.
Relevant skills to locate: configuration-authentication-ui; configuration-http-integrations; application-implementation.
Secondary context: https://docs.authcrunch.com/docs/apps/portal-apps

Design a disposable two-account check for all three app entries, forbidden administrative requests, disabled features, fresh local login and File Vault unlock. State which checks establish configuration versus actual runtime behavior.

Source Code References

Search the upstream implementations.
caddy-security configuration-authentication-ui (v1.6.2): Embedded app configuration boundaries.
portal_apps.go (go-authcrunch v1.5.0): Application names, namespaces and feature gates.
handle_http_apps.go (v1.5.0): Role checks, base injection, assets and SPA fallback.
handle_http_portal.go (v1.5.0): Per-user application links.
portal_apps_e2e_test.go (v1.5.0): Root/nested mounts and app access tests.
